- 250 Size 1400KV Outrunner Brushless Motor A2204-19T (<8 oz. plane)
, $17.95 (http://www.batteryheatedclothing.com/products/1400KV-Outrunner-Brushless-Motor-A2204-14T-less-than-8-oz.-plane.html))
Product Description
Motor Cross Reference Chart
| No. of Cells: | 2 - 3 Li-Poly 6 - 8 NiCd/NiMH |
| Kv: | 1400 RPM/V |
| Max Efficiency: | 77% |
| Max Efficiency Current: | 2 - 6A (>74%) |
| No Load Current: | 0.3A @10V |
| Resistance: | 0.550 ohms |
| Max Current: | 7.5A for 60S |
| Max Watts: | 75W |
| Weight: | 21.5 g / 0.76 oz |
| Size: | 27.6 mm x 11.5 mm |
| Shaft Diameter: | 3mm |
| Poles: | 14 |
| Model Weight: | 100 - 230g / 3.5 - 8 oz |
An excellent motor for planes up to 220 grams (8 oz) using 2 li-poly cells. Very lightweight at 21.5 grams including integral prop saver for APC 8x3.8 SloFly or APC 8x4 E propeller and integral firewall mount. Great for small 3D planes weighing around 6 oz, or aerobatic planes up to 8 oz. Use with a 10 Amp brushless ESC and small 7.4V lithium batteries in the 400mah - 800mah range.
The motor features a 3mm hardened steel shaft, dual ball bearings, integral prop saver for APC E props and integral firewall mount flange. Note that the prop saver is sized for APC props. GWS props will need some modification to fit properly. Countersunk mounting holes have 31mm spacing on centers.
Similar to: AXI 2203/52, AXI 2204/54
Io Test Data
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.5 | 10630 |
| 8 | 0.55 | 12230 |
| 10 | 0.6 | 15120 |
Test Data
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | Temp (C) |
|---|---|---|---|---|---|---|---|---|---|
| APC E 6x5.5 | 1 | 7 | 3 | 21 | 6870 | 35.8 | 97 | 3.42 | |
| APC E 6x5.5 | 1 | 7.9 | 3.45 | 27 | 7500 | 39.1 | 113 | 3.99 | |
| APC E 6x5.5 | 1 | 8.9 | 3.95 | 35 | 8040 | 41.9 | 134 | 4.73 | |
| APC E 6x5.5 | 1 | 9.9 | 4.5 | 44 | 8640 | 45.0 | 156 | 5.50 | |
| APC E 6x5.5 | 1 | 10.9 | 5 | 54 | 9060 | 47.2 | 175 | 6.17 | |
| GWS HD 7x3.5 | 1 | 7 | 2.3 | 16 | 7710 | 25.6 | 132 | 4.66 | |
| GWS HD 7x3.5 | 1 | 7.9 | 2.7 | 21 | 8460 | 28.0 | 162 | 5.71 | |
| GWS HD 7x3.5 | 1 | 8.9 | 3.1 | 27 | 9150 | 30.3 | 192 | 6.77 | |
| GWS HD 7x3.5 | 1 | 9.9 | 3.5 | 34 | 9840 | 32.6 | 227 | 8.01 | |
| GWS HD 7x3.5 | 1 | 10.9 | 3.95 | 43 | 10530 | 34.9 | 262 | 9.24 | |
| APC SF 7x4 | 1 | 7 | 3.15 | 22 | 6630 | 25.1 | 163 | 5.75 | |
| APC SF 7x4 | 1 | 7.9 | 3.7 | 29 | 7140 | 27.1 | 193 | 6.81 | |
| APC SF 7x4 | 1 | 8.9 | 4.25 | 37 | 7650 | 29.0 | 222 | 7.83 | |
| APC SF 7x4 | 1 | 9.9 | 4.8 | 47 | 8130 | 30.8 | 257 | 9.07 | |
| APC SF 7x4 | 1 | 10.9 | 5.4 | 58 | 8550 | 32.4 | 291 | 10.26 | |
| APC SF 7x6 | 1 | 6.9 | 3.85 | 26 | 5640 | 32.0 | 147 | 5.19 | |
| APC SF 7x6 | 1 | 7.9 | 4.5 | 35 | 6120 | 34.8 | 175 | 6.17 | |
| APC SF 7x6 | 1 | 8.9 | 5.25 | 46 | 6450 | 36.6 | 198 | 6.98 | |
| APC SF 7x6 | 1 | 9.9 | 5.9 | 58 | 6720 | 38.2 | 208 | 7.34 | |
| APC SF 7x6 | 1 | 10.9 | 6.5 | 70 | 6810 | 38.7 | 216 | 7.62 | |
| GWS HD 8x4 | 1 | 6.9 | 3.5 | 24 | 6120 | 23.2 | 191 | 6.74 | |
| GWS HD 8x4 | 1 | 7.4 | 3.85 | 28 | 6330 | 24.0 | 208 | 7.34 | |
| GWS HD 8x4 | 1 | 7.9 | 4.15 | 32 | 6570 | 24.9 | 223 | 7.87 | |
| GWS HD 8x4 | 1 | 8.9 | 4.75 | 42 | 6990 | 26.5 | 248 | 8.75 | |
| GWS HD 8x4 | 1 | 9.9 | 5.4 | 53 | 7440 | 28.2 | 283 | 9.98 |
